ORTOFON D-25M / D 25M / D25-M / D25 M / D25M / D 25 M NEEDLE STYLUS
This is a mono stylus. For stereo options, see the recommended upgrades below.
The Ortofon D-25M / D 25M / D25-M / D25 M / D25M / D 25 M stylus is the standard mono micro-groove replacement stylus for all Ortofon Super OM, OM, OMB, OMP, TM, and Concorde phono cartridges.
● Ortofon stylus specified for OM D25M cartridge
● Restores cartridge to its original factory specifications
● Special conical diamond tip for good fidelity
● 0.000984 inch (R 25 µm) radius for tracing accuracy
● Genuine, 100% authentic Ortofon stylus
|
Ortofon D25M D 25 M Stylus Specifications
|
|
Frequency range
|
20-20,000 Hz
|
|
Frequency response
|
20-18,000 Hz +3/-2 dB
|
|
FIM distortion at recommended tracking force, DIN 45.542
|
< 1%
|
|
Tracking ability at 315Hz at recommended tracking force
|
> 70 µm
|
|
Compliance, dynamic, lateral
|
7 µm/mN
|
|
Stylus type
|
Spherical
|
|
Stylus tip radius
|
0.98 mil
|
|
Tracking force range
|
2.0-3.0 g (20-30 mN)
|
|
Tracking force, recommended
|
2.5 g (25 mN)
|
|
Stylus grip color
|
Black
|
|
