The Vessel A3SM cartridge
The A3SM offers superlatives. Superb resolution, contrast and balance.
The Vessel A3SM Cartridge Specifications
- Type: Moving Magnet
- Frequency range: 20-35,000 Hz
- Output voltage @ 1kHz: 2.5 mV
- Channel balance @ 1kHz: <1.0dB
- Channel separation @ 1kHz: 24dB
- Dynamic compliance (100Hz): 10 10-6 cm/dyne
- Tracking ability at 2.0 g : 70 m
- Cantilever: Special type aluminum pipe
- Stylus type: Nude Super Micro Line
- Stylus tip radius: .000079 x .003 inch
- Tracking force: 2.0 g
- Internal impedance @ 1kHz: 670 ohms
- Internal inductance: 285 mH
- Recommended load resistance: 47 kOhm
- Cartridge color, body/stylus: Black/Gold/Black
- Weight: 6.0 g
- Mounting hardware included: 2 Screws, 2 Nuts
- Stylus replacement: A3SM stylus
