The Vessel A3SS cartridge
Music is expressed manifold with the elegance and grace of the A3SS cartridge. Its Super Shibata stylus delivers complex texture and dynamism with stellar liquidity and transparency.
The Vessel A3SS Cartridge Specifications
- Type: Moving Magnet
- Frequency range: 20-30,000 Hz
- Output voltage @ 1kHz: 2.5 mV
- Channel balance @ 1kHz: <1.0dB
- Channel separation @ 1kHz: 23dB
- Dynamic compliance (100Hz): 10 10-6 cm/dyne
- Tracking ability at 2.0 g : 70 m
- Cantilever: Special type aluminum pipe
- Stylus type: Nude Super Shibata
- Stylus tip radius: .00016 x .0028 inch
- Tracking force: 2.0 g
- Internal impedance @ 1kHz: 670 ohms
- Internal inductance: 285 mH
- Recommended load resistance: 47 kOhm
- Cartridge color, body/stylus: Black/Gold/Green
- Weight: 6.0 g
- Mounting hardware included: 2 Screws, 2 Nuts
- Stylus replacement: A3SS stylus
