LP Tunes N-312 III STR Stylus for Acutex M 320 III STR Cartridge (Early Version)

LP TUNES N-312 III STR STYLUS FOR ACUTEX M320 III STR CARTRIDGE - EARLY VERSION

The LP Tunes N 312 III STR stylus for the early version of the Acutex M 320 III M320 III M 320III STR cartridge features a highly polished Nude elliptical diamond tip for long playing life, excellent tracing characteristics, superb sound quality and very accurate reproduction of voice and music. The color of the stylus replacement may vary from the black original.

● NSS/e LP Tunes stylus for Acutex M 320 III STR cartridge (early version)
● Excellent accuracy, fidelity and sound quality
● Diamond tip r/R radii: 6/75 µm (.0002 × .0030 inch)
● Special type cantilever for firm and sensitive response to grooves
● Advanced type cantilever for firm and sensitive response to grooves
● Made by select very skilled stylus artisans
● LP TUNES® stylus - Above and beyond copies and generics

ACUTEX M320IIISTR Improved Cartridge Specifications:
○ Tonearm mount: 1/2 inch or 12.7 mm
○ Type: Tri Pole Induced Magnet
○ Output voltage at 1kHz, 5 cm/sec: 3.8 mV
○ Frequency response: 20 - 45,000 Hz
○ Load impedance: 47 kΩ
○ Channel separation: 32 dB at 1 kHz / 29 db at 10 kHz
○ Output balance at 1 kHz: within 1.0 dB
○ Tracking force range: 0.8 - 1.8 g
○ Compliance: 42 x 10-6 cm/dyne
○ Stylus: Nude Special Symmetrical Tri-Radial (SBR)
○ Cantilever: Special aluminum alloy
○ Vertical tracking angle: 15°
○ Dimensions: 17.5(H) × 17(W) × 29.0(D) mm
○ Weight: 6.2 g
○ Accessories included: 6 screws, 4 nuts, 2 washers, 1 screwdriver, 1 brush

Note: Specifications provided for reference only to original product.

This is the highest quality needle in this series. Please see the Related Products section near the bottom of this page for other needles in this series and some phono essentials to keep your vinyl and your stylus clean.
