Audio-Technica

AUDIO-TECHNICA VM670SP CARTRIDGE

Designed for playing 78 RPM records with the highest fidelity, the VM670SP cartridge features a specialized body and internal wiring dedicated to monaural sound reproduction, Additionally, it is equipped with dual magnets that are internally connected to reduce record noise and obtain a highly focused "center" sound image that stereo cartridges can't provide. The stylus's 3.0 mil curvature radius makes it an excellent choice for playing 78s from a wide variety of eras.

Audio-Technica VM670SP cartridge specifications
- Type: VM
- Frequency response: 20 ~ 20,000 Hz
- Output voltage: 3.0 mV (1kHz, 5 cm/sec.)
- Channel separation: Not applicable
- Output balance: Not applicable
- Tracking force: 4.5 ~ 5.5 g (5.0 g standard)
- Coil impedance: 1.4 kΩ (1kHz)
- DC resistance: 400 Ω
- Load impedance: 47 kΩ
- Load capacitance: 100 ~ 200 pF
- Coil inductance: 230 mH (1kHz)
- Static compliance: 15 10-6 cm/dyne
- Dynamic compliance: 2 10-6 cm/dyne (100Hz)
- Stylus: Bonded conical (3.0 mil)
- Cantilever: Aluminum pipe
- Vertical tracking angle: 23
- Dimensions: 17.3(H) 17.0(W) 28.2(D) mm
- Weight: 6.4 g
- Replacment stylus: VMN70SP - Accessories: Cartridge installtion screws 5mm 2, 10 mm 2, Washer 2, Hexagon nut 2

Note: Specifications are subject to change without notice.

Audio Technica's VM740ML phono cartridge features a MicroLine stylus which enables extremely accurate groove tracking. The VM740ML is furnished with a die-cast aluminum alloy housing which reduces vibration and parasitic resonance distortion while adding a natural electrical shield. Comparatively, the VM540ML is furnished with a durable low-resonance polymer housing. The housing difference results in a more subtle and refined presentation by the 740ML. Both the VM740ML and VM540ML are equipped with a VMN40ML MicroLine nude stylus that traces the groove with incredible accuracy, resulting in nuanced audio reproduction that elliptical and conical styli simply can't match. The stylus's multilevel shape also wears better than other styli, while reducing the wear on your records.

Audio-Technica VM740ML cartridge specifications
- Type: VM
- Frequency response: 20 ~ 27,000 Hz
- Output voltage: 4.0 mV (1kHz, 5 cm/sec.)
- Channel separation: 30 dB (1kHz)
- Output balance: 1.0 dB (1kHz)
- Tracking force: 1.8 ~ 2.2 g (2.0 g standard)
- Coil impedance: 2.7 kΩ (1kHz)
- DC resistance: 800 Ω
- Load impedance: 47 kΩ
- Load capacitance: 100 ~ 200 pF
- Coil inductance: 460 mH (1kHz)
- Static compliance: 40 × 10-6 cm/dyne
- Dynamic compliance: 10 × 10-6 cm/dyne (100Hz)
- Stylus: Nude MicroLine (2.2 × 0.12 mil)
- Cantilever: Aluminum tapered pipe
- Vertical tracking angle: 23 °
- Dimensions: 17.3(H) × 17.0(W) × 28.2(D) mm
- Weight: 8.0 g
- Replacment stylus: VMN40ML
- Accessories: Cartridge installation screws 5mm × 2, 10 mm × 2, Washer × 2, Hexagon nut × 2, Non-magnetic screwdriver × 1, Brush × 1, Lead wire set × 1,

Note: Specifications are subject to change without notice.

AUDIO-TECHNICA VM750SH CARTRIDGE

Audio Technica's VM750SH phono cartridge with its Nude Shibata stylus is ideal for reproducing rich smooth ultra-high frequencies, and full-bodied mid and low frequencies. The VM750SH is furnished with a die-cast aluminum alloy housing which reduces vibration while adding a natural electrical shield.

Audio-Technica VM750SH cartridge specifications
- Type: VM
- Frequency response: 20 ~ 27,000 Hz
- Output voltage: 4.0 mV (1kHz, 5 cm/sec.)
- Channel separation: 30 dB (1kHz)
- Output balance: 1.0 dB (1kHz)
- Tracking force: 1.8 ~ 2.2 g (2.0 g standard)
- Coil impedance: 2.7 kΩ (1kHz)
- DC resistance: 800 Ω
- Load impedance: 47 kΩ
- Load capacitance: 100 ~ 200 pF
- Coil inductance: 460 mH (1kHz)
- Static compliance: 40 10-6 cm/dyne
- Dynamic compliance: 10 10-6 cm/dyne (100Hz)
- Stylus: Nude Shibata (2.7 0.26 mil)
- Cantilever: Aluminum tapered pipe
- Vertical tracking angle: 23
- Dimensions: 17.3(H) 17.0(W) 28.2(D) mm
- Weight: 8.0 g
- Replacment stylus: VMN50SH
- Accessories: Cartridge installtion screws 5mm 2, 10 mm 2, Washer 2, Hexagon nut 2, Non-magnetic screwdriver 1, Brush 1, Lead wire set 1

Note: Specifications are subject to change without notice.

AUDIO-TECHNICA VM760SLC CARTRIDGE

The VM760SLC special line contact stylus cartridge is the flagship model in Audio-Technica's new VM cartridge line a line that harks back to A-T's early days as a manufacturer primarily of high-end phono cartridges, while also incorporating today's advanced technology. Like all VM cartridges, the VM760SLC is equipped with dual magnets that are positioned to match the left and right channels in the stereo record groove for outstanding channel separation and extended frequency response. The cartridge's ultra-lightweight special line contact stylus allows it to trace the record groove with incredible accuracy and minimum abrasion, resulting in nuanced audio reproduction, low distortion and low record wear.

Audio-Technica VM760SLC cartridge specifications
- Type: VM
- Frequency response: 20 ~ 30,000 Hz
- Output voltage: 4.0 mV (1kHz, 5 cm/sec.)
- Channel separation: 30 dB (1kHz)
- Output balance: 1.0 dB (1kHz)
- Tracking force: 1.8 ~ 2.2 g (2.0 g standard)
- Coil impedance: 2.7 kΩ (1kHz)
- DC resistance: 800 Ω
- Load impedance: 47 kΩ
- Load capacitance: 100 ~ 200 pF
- Coil inductance: 460 mH (1kHz)
- Static compliance: 40 10-6 cm/dyne
- Dynamic compliance: 10 10-6 cm/dyne (100Hz)
- Stylus: Nude Special Line Contact (1.5 0.28 mil)
- Cantilever: Aluminum tapered pipe
- Vertical tracking angle: 23
- Dimensions: 17.3(H) 17.0(W) 28.2(D) mm
- Weight: 8.0 g
- Replacement stylus: VMN60SLC
- Accessories: Cartridge installation screws 5mm 2, 10 mm 2, Washer 2, Hexagon nut 2, Non-magnetic screwdriver 1, Brush 1, Lead wire set 1

Note: Specifications are subject to change without notice.

AUDIO-TECHNICA VMN10CB STYLUS
- For VM610MONO, VM510CB, 6 mil.

Discontinued. Please see the 100% compatible LP Tunes Conical Replacement for the Audio-Technica ATN103 ATN-103 Stylus, or the recommended Product Options below.

Stylus replacement for VM610 cartridge. Audio-Technica VMN10MONO cartridge specifications
- Type: VM
- Frequency response: 20 ~ 20,000 Hz
- Output voltage: 3.0 mV (1kHz, 5 cm/sec.)
- Static compliance: 35 × 10-6 cm/dyne
- Dynamic compliance: 8 × 10-6 cm/dyne (100Hz)
- Stylus: Bonded conical (0.6 mil)
- Cantilever: Aluminum pipe
- Vertical tracking angle: 23 °

Note: Specifications are subject to change without notice.

AUDIO-TECHNICA VMN20EB STYLUS

Discontinued. Please see the 100% compatible LP Tunes Elliptical AIN20SE Replacement for the Audio-Technica VMN20EB Stylus, or the recommended Product Options below.

Stylus replacement for VM520EB cartridge.

Audio-Technica VM20 stylus specifications
- Tracking force: 1.8 ~ 2.2 g (2.0 g standard)
- Static compliance: 35 × 10-6 cm/dyne
- Dynamic compliance: 8 × 10-6 cm/dyne (100Hz)
- Stylus: Bonded elliptical (0.3 × 0.7 mil)
- Cantilever: Aluminum pipe
- Vertical tracking angle: 23 °

Note: Specifications are subject to change without notice.

Alternative Stylus
- For High Grade stylus and accessories that enhance sound quality and fidelity, refer to Related Products.

AUDIO-TECHNICA VMN30EN STYLUS

Audio Technicas VMN30EN stylus for the Audio Technica VM530EN phono cartridge and others features a 0.3 x 0.7 mil elliptical nude stylus which follows the record grooves with more precision while providing lower distortion.

Audio-Technica VMN30EN Stylus Specifications
- Frequency response: 20Hz-25kHz
- Output voltage @ 1kHz,5cm/sec.: 4.5mV
- Channel balance: 1.5dB
- Channel separation @ 1kHz: 27dB
- Stylus type: 0.3x0.7mil Nude Elliptical
- Cantilever: Aluminum pipe
- Tracking force range: 1.8-2.2g
- Tracking force recommended: 2.0g
- Color: Yellow

AUDIO-TECHNICA VMN30EN STYLUS FOR AUDIO-TECHNICA AT-140EaG AT140EaG CARTRIDGE

The Audio-Technica VMN30EN stylus for the Audio-Technica AT-140EaG AT140EaG phono cartridge features a highly polished Nude Elliptical diamond for superb tracking and tracing of record grooves. It results in finer detail and harmonically complete sound quality. The stylus is made in Japan by Audio-Technica a world-class manufacturer.

Audio-Technica VM30EN stylus specifications
- Tracking force: 1.8 ~ 2.2 g (2.0 g standard)
- Static compliance: 35 × 10-6 cm/dyne
- Dynamic compliance: 8 × 10-6 cm/dyne (100Hz)
- Stylus: Nude elliptical (0.3 × 0.7 mil)
- Cantilever: Aluminum pipe
- Vertical tracking angle: 23 °
- Color: Orange

Note: Specifications are subject to change without notice.

AUDIO-TECHNICA VMN40ML STYLUS FOR THE AUDIO-TECHNICA VM540ML VM740ML CARTRIDGES AND OTHERS

VM540ML Specs:

Audio-Technica VMN40ML Stylus Specifications
- Frequency response: 20Hz-27kHz
- Output voltage @ 1kHz,5cm/sec.: 4.0mV
- Channel balance: 1.0dB
- Channel separation @ 1kHz: 28dB
- Stylus type: 2.2x0.12mil Nude MicroLine
- Cantilever: Aluminum tapered pipe
- Tracking force range: 1.8-2.2g
- Tracking force recommended: 2.0g
- Color: Red

AUDIO-TECHNNICA VMN40ML STYLUS FOR AUDIO-TECHNICA VM540ML CARTRIDGE

The Audio-Technica VMN40ML is specified as the standard stylus replacement for the VM540ML cartridge. It will bring the VM540ML's performance back to original factory specifications.

● Genuine Audio-Technica VMN40ML stylus For VM540ML, VM740ML cartrudge.
● Nude MicroLine (2.2 × 0.12 mil)
● Exquisitely crafted and precision engineered in Japan
● Finest quality available by the original manufacturer
● Curated by LP Tunes® for long-term listening pleasure

AUDIO-TECHNICA AT-VMN50SH VMN50SH STYLUS

Discontinued. Out of stock. Please see the 100% compatible LP Tunes Nude Shibata AIN50SS Replacement for the Audio-Technica AT-VMN50SH and AT-VMN50xSH Stylus, the Audio-Technica AT-VMN50xSH Stylus for the AT-VM50xSH, or the recommend Product Options below.

Stylus replacement for AT-VM750SH cartridge and others.

Audio-Technica AT-VMN50SH stylus specifications
- Type: VM
- Frequency response: 20 ~ 27,000 Hz
- Output voltage: 4.0 mV (1kHz, 5 cm/sec.)
- Tracking force: 1.8 ~ 2.2 g (2.0 g standard)
- Static compliance: 40 × 10-6 cm/dyne
- Dynamic compliance: 10 × 10-6 cm/dyne (100Hz)
- Stylus: Nude Shibata (2.7 × 0.26 mil)
- Cantilever: Aluminum tapered pipe
- Vertical tracking angle: 23 °

Note: Specifications are subject to change without notice.

AUDIO-TECHNICA VMN60SLC STYLUS

Replacement stylus for VM60SLC cartridge and others

Audio-Technica VMN60SLC stylus specifications
- Tracking force: 1.8 ~ 2.2 g (2.0 g standard)
- Static compliance: 40 × 10-6 cm/dyne
- Dynamic compliance: 10 × 10-6 cm/dyne (100Hz)
- Stylus: Nude Special Line Contact (1.5 × 0.28 mil)
- Cantilever: Aluminum tapered pipe
- Vertical tracking angle: 23 °

Note: Specifications are subject to change without notice.

AUDIO-TECHNICA VMN70SP stylus

The VMN70SP is speficied as replacement stylus for the 78 RPM Audio-Technica VM-670SP cartridge and other cartridges within the series.

Audio-Technica VMN70SP stylus specifications
- Type: VM
- Frequency response: 20 ~ 20,000 Hz
- Output voltage: 3.0 mV (1kHz, 5 cm/sec.)
- Tracking force: 4.5 ~ 5.5 g (5.0 g standard)
- Static compliance: 15 × 10-6 cm/dyne
- Dynamic compliance: 2 × 10-6 cm/dyne (100Hz)
- Stylus: Bonded conical (3.0 mil)
- Cantilever: Aluminum pipe
- Vertical tracking angle: 23 °

Note: Specifications are subject to change without notice.

IMPROVED STYLUS FOR AUDIO-TECHNICA PRECEPT PC-110 PC110 CARTRIDGE

The LP Tunes Improved Stylus for the Audio-Technica Precept PC-110 PC110 cartridge features a finely polished .0003 x ..0007 elliptical tip, which is an upgrade over the .0004 x .0007 elliptical tip found on the original Precept PCN-110 PCN110 Stylus. It offers accurate tracing of record grooves, long playing life and harmonically rich and detailed sound quality. Color of stylus varies.

For a stylus replacement that offers improved sound quality and performance, refer to the Related Products.

JICO REPLACEMENT AUDIO-TECHNICA AT-5D AT5D AT 5D STYLUS

The AT-5D stylus performs well with its polished 0.7 mil conical diamond tip while providing the user with long playing life and accuracy.

The color of this stylus has changed over the years. Please be sure to compare your stylus with this stylus before ordering. Do not order this stylus if it looks different than the stylus that you have.

⚠ If you are unsure if this is the correct stylus please contact us here

 Beware of counterfeits! There is only one Jico distributor in the US, Canada and all of the Americas: LP Tunes. A Jico stylus comes in Jico packaging or with Jico US engraved on the stylus. All others are selling styli of unknown origin and quality. Contact us to verify the authenticity of the claimed Jico stylus before buying.
