AUDIO-TECHNICA STYLUS FOR AUDIO-TECHNICA AT-30E AT30E CARTRIDGE

The Audio-Technica ATN-30E ATN30E needle stylus for the highly regarded low-output moving coil Audio-Technica AT-30E AT30E phono cartridge is deactivated and is no longer available. The stylus was made in Japan by Audio-Technica.

For the Audio-Technica ATN-31E ATN31E needle stylus, refer to the Related Products.

AUDIO-TECHNICA STYLUS FOR AUDIO-TECHNICA AT-30HE AT30HE CARTRIDGE

The Audio-Technica ATN-30HE ATN30HE needle stylus for the highly regarded high-output moving coil Audio-Technica AT-30HE AT30HE phono cartridge features an elliptical diamond with a .0003 x .0007 inch scanning radii. It offers superb tracing of record grooves, long playing life and excellent reproduction and rendition of voice, music and harmonics. The stylus assembly may be disconnected and replaced more than 2,000 times with no appreciable increase in output noise. The stylus is made in Japan by Audio-Technica.

Audio-Technica ATN30HE Stylus Specifications
- Frequency Response: 15Hz-25kHz
- Output voltage @ 1kHz,5cm/sec: 2.0mV
- Channel separation @ 1kHz: Minimum 29dB
- Channel balance @ 1kHz: Within 1dB
- Tracking force: 1.4 - 1.8 g (Nominal force 1.5 g)
- Static compliance: 32 x 10-6 cm/dyne
- Load resistance: 47k ohms

AUDIO-TECHNICA STYLUS FOR AUDIO-TECHNICA AT-312EP AT312EP CARTRIDGE

The Audio-Technica ATN-312EP ATN312EP stylus for the T4P P-mount Audio-Technica Dual Moving Coil AT-312EP AT312EP phono cartridge features a highly polished elliptical diamond for superb tracking and tracing of record grooves. It results in finer detail and harmonically complete sound quality. The stylus is made in Japan by Audio-Technica.

Audio-Technica ATN312EP Specifications
- Type: Moving Coil
- Frequency response: 15 ~ 50,000 Hz
- Output voltage: 0.4 mV
- Output impedance: 10 Ω
- Stylus: Elliptical 0.3 x 0.7 mil
- Dynamic compliance: 10 10-6 cm/dyne
- Tracking force: 1.0-1.5g (1.25g standard)

AUDIO-TECHNICA STYLUS FOR AUDIO-TECHNICA AT-312HEP AT312HEP CARTRIDGE

The Audio-Technica ATN-312EP ATN312EP needle stylus for the Audio-Technica AT-312HEP AT312HEP phono cartridge features a highly polished elliptical diamond for superb tracking and tracing of record grooves. It results in finer detail and harmonically complete sound quality. The stylus is made in Japan by Audio-Technica.

Audio-Technica ATN312EP Specifications
- Type: Moving Coil
- Frequency response: 15 ~ 50,000 Hz
- Output voltage: 0.4 mV
- Output impedance: 10 Ω
- Stylus: Elliptical 0.3 x 0.7 mil
- Dynamic compliance: 10 10-6 cm/dyne
- Tracking force: 1.0-1.5g (1.25g standard)

AUDIO-TECHNICA STYLUS FOR AUDIO-TECHNICA AT-312P AT312P CARTRIDGE

The Audio-Technica ATN-312EP ATN312EP needle stylus for the Audio-Technica AT-312P AT312P phono cartridge features a highly polished elliptical diamond for superb tracking and tracing of record grooves. It results in finer detail and harmonically complete sound quality. The stylus is made in Japan by Audio-Technica.

Audio-Technica ATN312EP Specifications
- Type: Moving Coil
- Frequency response: 15 ~ 50,000 Hz
- Output voltage: 0.4 mV
- Output impedance: 10 Ω
- Stylus: Elliptical 0.3 x 0.7 mil
- Dynamic compliance: 10 10-6 cm/dyne
- Tracking force: 1.0-1.5g (1.25g standard)

AUDIO-TECHNICA STYLUS FOR AUDIO-TECHNICA AT-312S AT312S CARTRIDGE

The Audio-Technica ATN-12S ATN12S needle stylus for the Audio-Technica AT-312S AT312S phono cartridge features the highly acclaimed Shibata diamond tip for superior tracking and tracing of record grooves. It offers excellent rendition of voice and music with harmonically complete sound quality. The stylus is made in Japan by Audio-Technica.

Stylus Alternative and Options
- For stylus alternative and accessories that enhance sound quality and fidelity, refer to Related Products.

AUDIO-TECHNICA STYLUS FOR AUDIO-TECHNICA AT-31E AT31E CARTRIDGE

The Audio-Technica ATN-31E ATN31E needle stylus for the highly regarded low-output moving coil Audio-Technica AT-31E AT31E phono cartridge features a nude elliptical diamond with a .0003 x .0007 inch scanning radii. It offers superb tracing of record grooves, long playing life and excellent reproduction and rendition of voice, music and harmonics. The stylus assembly may be disconnected and replaced more than 2,000 times with no appreciable increase in output noise. The stylus is made in Japan by Audio-Technica.

Audio-Technica ATN31E Stylus Specifications
- Frequency response: 15Hz-50kHz
- Output voltage @ 1kHz, 5 cm/sec: 0.4mV
- Channel separation @ 1kHz: Minimum 30dB
- Channel balance @ 1kHz: Within 1.0dB
- Tracking force: 1.2 - 1.8 g (Nominal force 1.5 g)
- Dynamic compliance: 8.5 x 10-6 cm/dyne (100 Hz)
- Static compliance: 32 x 10-6 cm/dyne
- Load resistance: More than 10 ohms
- Load capacitance: 100 - 200 pf
- Stylus: 0.15 mm nude square, 0.3 x 0.7 mil elliptical diamond

AUDIO-TECHNICA STYLUS FOR AUDIO-TECHNICA AT-3200XE II AT3200XE II CARTRIDGE

The Audio-Technica ATN-3100E ATN3100E needle stylus for the Audio-Technica AT-3200XE II AT3200XE II phono cartridge features a highly polished special elliptical diamond with .0003 x .0007 inch scanning radii. It offers superior tracing characteristic and excellent rendition of voice, music and harmonic detail. The stylus is made in Japan by Audio-Technica.

AUDIO-TECHNICA STYLUS FOR AUDIO-TECHNICA AT-3312S AT3312S CARTRIDGE

Out of stock. Please see the 100% compatible Audio-Technica Shibata ATS-12S ATS12S Replacement Stylus (without guard), or the recommended Product Option below.

The Audio-Technica ATN-12S ATN12S needle stylus for the Audio-Technica AT-3312S AT3312S phono cartridge features the highly acclaimed Shibata diamond tip for superior tracking and tracing of record grooves. It offers excellent rendition of voice and music with harmonically complete sound quality. The stylus is made in Japan by Audio-Technica.

Stylus Alternative and Options
- For stylus alternative and accessories that enhance sound quality and fidelity, refer to Related Products.

AUDIO-TECHNICA STYLUS FOR AUDIO-TECHNICA AT-3500S AT3500S CARTRIDGE

Out of stock. Please see the 100% compatible Audio-Technica Shibata ATS-12S ATS12S Replacement Stylus (without guard), or the recommended Product Option below.

The Audio-Technica ATN-12S ATN12S needle stylus for the Audio-Technica AT-3500S AT3500S phono cartridge features the highly acclaimed Shibata diamond tip for superior tracking and tracing of record grooves. It offers excellent rendition of voice and music with harmonically complete sound quality. The stylus is made in Japan by Audio-Technica.

Stylus Alternative and Options
- For stylus alternative and accessories that enhance sound quality and fidelity, refer to Related Products.

AUDIO-TECHNICA STYLUS FOR AUDIO-TECHNICA AT-35E AT35E CARTRIDGE

The Audio-Technica ATN-35E ATN35E needle stylus for the low-output moving coil Audio-Technica AT-35E AT35E phono cartridge features a square-shank nude special elliptical diamond with a .0002 x .0007 inch scanning radii. It offers natural sound reproduction, long playing life, very high fidelity, dynamics and very high resolution. The stylus is made in Japan by Audio-Technica.

Audio-Technica ATN35E Stylus Specifications
- Frequency response: 15Hz-30kHz
- Output voltage @ 1kHz,5cm/sec: 0.4mV
- Channel separation @ 1kHz: Minimum 30dB
- Channel balance @ 1kHz: 1dB
- Tracking force: 1.2-1.8g (nominal force 1.5g)
- Load resistance: >10 ohms
- Load capacitance: 100-200pf
- Stylus: 0.15 mm nude square, 0.2 x 0.7 mil elliptical diamond

AUDIO-TECHNICA STYLUS FOR AUDIO-TECHNICA AT-3831 AT3831 CARTRIDGE

The Audio-Technica ATN-3831 ATN3831 needle stylus for the Audio-Technica AT-3831 AT3831 phono cartridge features a highly polished conical diamond for long playing life and good rendition of voice and music. The stylus is made in Japan by Audio-Technica.

AUDIO-TECHNICA STYLUS FOR AUDIO-TECHNICA AT-4012XE AT4012XE CARTRIDGE

The Audio-Technica needle stylus for the Audio-Technica AT-4012XE AT4012XE phono cartridge is designed to meet factory specifications and performance. The stylus features a highly polished conical diamond tip for long playing life, reduced record wear and good rendition of voice and music. The stylus is made in Japan by Audio-Technica.

For a stylus replacement that offers improved sound quality and performance, refer to the Related Products.

AUDIO-TECHNICA STYLUS FOR AUDIO-TECHNICA AT-4020XE AT4020XE CARTRIDGE

The Audio-Technica needle stylus for the Audio-Technica AT-4020XE AT4020XE phono cartridge is designed to meet factory specifications and performance. The stylus features a highly polished conical diamond tip for long playing life, reduced record wear and good rendition of voice and music. The stylus is made in Japan by Audio-Technica.

For a stylus replacement that offers improved sound quality and performance, refer to the Related Products.

AUDIO-TECHNICA STYLUS FOR AUDIO-TECHNICA AT-4025XE AT4025XE CARTRIDGE

The Audio-Technica ATN-12S ATN12S needle stylus for the Audio-Technica AT-4025XE AT4025XE phono cartridge features the highly acclaimed Shibata diamond tip for superior tracking and tracing of record grooves. It offers excellent rendition of voice and music with harmonically complete sound quality. The stylus is made in Japan by Audio-Technica.

Stylus Alternative and Options
- For stylus alternative and accessories that enhance sound quality and fidelity, refer to Related Products.
