ORTOFON STYLUS FOR ORTOFON OM-5 OM5 CARTRIDGE

The Ortofon Stylus 5E needle stylus for the Ortofon OM-5 OM5 phono cartridge features a highly polished elliptical diamond for superb tracking and tracing of record grooves. It results in finer detail and harmonically complete sound quality.

If you seek further listening pleasure and improved sound quality, you can easily upgrade to a higher level of performance by replacing the Ortofon Stylus 5E stylus with an Ortofon Stylus 10, 20, 30 or 40 stylus.

Ortofon Stylus 5E Specifications
- Frequency range: 20Hz-25kHz
- Frequency response: 20Hz-20kHz +2dB
- FIM distortion at recommended tracking force, DIN 45.542: < 1%
- Tracking ability @ 315Hz @ recommended tracking force: 65µm
- Compliance, dynamic, lateral: 20µm/mN
- Stylus type: Elliptical
- Stylus tip radius: 0.3 x 0.7 mil
- Tracking force range: 1.5-2.0g (15-20mN)
- Tracking force, recommended: 1.75g (17.5mN)
- Color: Black

ORTOFON STYLUS FOR ORTOFON OM-5E OM5E CARTRIDGE

The Ortofon Stylus 5E needle stylus for the Ortofon OM-5E OM5E phono cartridge features a highly polished elliptical diamond for superb tracking and tracing of record grooves. It results in finer detail and harmonically complete sound quality.

If you seek further listening pleasure and improved sound quality, you can easily upgrade to a higher level of performance by replacing the Ortofon Stylus 5E stylus with an Ortofon Stylus 10, 20, 30 or 40 stylus.

Ortofon Stylus 5E Specifications
- Frequency range: 20Hz-25kHz
- Frequency response: 20Hz-20kHz +2dB
- FIM distortion at recommended tracking force, DIN 45.542: < 1%
- Tracking ability @ 315Hz @ recommended tracking force: 65µm
- Compliance, dynamic, lateral: 20µm/mN
- Stylus type: Elliptical
- Stylus tip radius: 0.3 x 0.7 mil
- Tracking force range: 1.5-2.0g (15-20mN)
- Tracking force, recommended: 1.75g (17.5mN)
- Color: Black

ORTOFON STYLUS FOR ORTOFON OM-78 OM78 CARTRIDGE

The Ortofon Stylus 78 for the Ortofon OM-78 OM78 phono cartridge features a 2.5 mil diamond for tracing 78 RPM record grooves. It results in minimal groove wear and an accurate rendition of voice and music. The stylus is made in Japan by a world-class manufacturer with a reputation for crafting musically excellent and high-quality replacement styli.

A very common misconception is that you can use an LP stylus for playing 78 RPM records. This is one quick and sure way to damage the 78 RPM record grooves. To maintain the playback fidelity of your 78 record, you really need to use a stylus designed for 78 RPM records, otherwise with just a single playing, you could ruin the fidelity of the record grooves. Moreover, the LP stylus is much narrower than the 78 RPM record groove hence the tip will slide to the bottom of the groove where debris has collected for many decades. This results in extraordinarily high-surface noise.

Ortofon Stylus 78 Specifications
- Frequency range: 20Hz-15kHz
- Frequency response: 20-12kHz +/- 2dB
- FIM distortion @ recommended tracking force, DIN 45.542: <1%
- Tracking ability @ 315Hz @ recommended tracking force: 60µm
- Compliance, dynamic, lateral: 15µm/mN
- Stylus type: Spherical
- Stylus tip radius: 2.5 mil
- Tracking force range: 1.75 - 2.25 g (17.5 - 22.5 mN)
- Tracking force, recommended: 2.0 g (20.0 mN)
- Color: Black

ORTOFON STYLUS FOR ORTOFON OMB-5E OMB5E CARTRIDGE

The Ortofon Stylus 5E needle stylus for the Ortofon OMB-5E OMB5E phono cartridge features a highly polished elliptical diamond for superb tracking and tracing of record grooves. It results in finer detail and harmonically complete sound quality.

If you seek further listening pleasure and improved sound quality, you can easily upgrade to a higher level of performance by replacing the Ortofon Stylus 5E stylus with an Ortofon Stylus 10, 20, 30 or 40 stylus.

Ortofon Stylus 5E Specifications
- Frequency range: 20Hz-25kHz
- Frequency response: 20Hz-20kHz +2dB
- FIM distortion at recommended tracking force, DIN 45.542: < 1%
- Tracking ability @ 315Hz @ recommended tracking force: 65µm
- Compliance, dynamic, lateral: 20µm/mN
- Stylus type: Elliptical
- Stylus tip radius: 0.3 x 0.7 mil
- Tracking force range: 1.5-2.0g (15-20mN)
- Tracking force, recommended: 1.75g (17.5mN)
- Color: Black

ORTOFON STYLUS FOR ORTOFON OMB-5 OMB5 CARTRIDGE

The Ortofon Stylus 5E needle stylus for the Ortofon OMB-5 OMB5 phono cartridge features a highly polished elliptical diamond for superb tracking and tracing of record grooves. It results in finer detail and harmonically complete sound quality.

If you seek further listening pleasure and improved sound quality, you can easily upgrade to a higher level of performance by replacing the Ortofon Stylus 5E stylus with an Ortofon Stylus 10, 20, 30 or 40 stylus.

Ortofon Stylus 5E Specifications
- Frequency range: 20Hz-25kHz
- Frequency response: 20Hz-20kHz +2dB
- FIM distortion at recommended tracking force, DIN 45.542: < 1%
- Tracking ability @ 315Hz @ recommended tracking force: 65µm
- Compliance, dynamic, lateral: 20µm/mN
- Stylus type: Elliptical
- Stylus tip radius: 0.3 x 0.7 mil
- Tracking force range: 1.5-2.0g (15-20mN)
- Tracking force, recommended: 1.75g (17.5mN)
- Color: Black

ORTOFON STYLUS FOR ORTOFON OMB-78 OMB78 CARTRIDGE

The Ortofon Stylus 78 for the Ortofon OMB-78 OMB78 phono cartridge features a 2.5 mil diamond for tracing 78 RPM record grooves. It results in minimal groove wear and an accurate rendition of voice and music. The stylus is made in Japan by a world-class manufacturer with a reputation for crafting musically excellent and high-quality replacement styli.

A very common misconception is that you can use an LP stylus for playing 78 RPM records. This is one quick and sure way to damage the 78 RPM record grooves. To maintain the playback fidelity of your 78 record, you really need to use a stylus designed for 78 RPM records, otherwise with just a single playing, you could ruin the fidelity of the record grooves. Moreover, the LP stylus is much narrower than the 78 RPM record groove hence the tip will slide to the bottom of the groove where debris has collected for many decades. This results in extraordinarily high-surface noise.

Ortofon Stylus 78 Specifications
- Frequency range: 20Hz-15kHz
- Frequency response: 20Hz-12kHz +/- 2dB
- FIM distortion @ recommended tracking force, DIN 45.542: <1%
- Tracking ability @ 315Hz @ recommended tracking force: 60µm
- Compliance, dynamic, lateral: 15µm/mN
- Stylus type: Spherical
- Stylus tip radius: 2.5 mil
- Tracking force range: 1.75 - 2.25 g (17.5 - 22.5 mN)
- Tracking force, recommended: 2.0 g (20.0 mN)
- Color: Black

ORTOFON STYLUS FOR ORTOFON OMP-3E OMP3E CARTRIDGE

The Ortofon Stylus 3E needle stylus is the standard replacement stylus for the Ortofon OMP-3E OMP3E phono cartridge and its siblings.

For a stylus replacement that offers improved sound quality and performance, refer to the Related Products below.

Ortofon Stylus 3E Specifications
-Frequency range: 20-20kHz
-FIM distortion at recommended tracking force, DIN 45.542: < 1%
-Tracking ability @ 315Hz @ recommended tracking force: 60µm
-Compliance, dynamic, lateral: 20µm/mN
-Stylus type: Elliptical
-Stylus tip radius: 0.3 x 0.7 mil
-Tracking force range: 1.5-2.0g (15-20mN)
-Tracking force, recommended: 1.75g (17.5mN)
-Color: Black

ORTOFON STYLUS FOR ORTOFON OMP-5E OMP5E CARTRIDGE

The Ortofon Stylus 5E needle stylus for the Ortofon OMP-5E OMP5E phono cartridge features a highly polished elliptical diamond for superb tracking and tracing of record grooves. It results in finer detail and harmonically complete sound quality.

If you seek further listening pleasure and improved sound quality, you can easily upgrade to a higher level of performance by replacing the Ortofon Stylus 5E stylus with an Ortofon Stylus 10, 20, 30 or 40 stylus.

Ortofon Stylus 5E Specifications
- Frequency range: 20Hz-25kHz
- Frequency response: 20Hz-20kHz +2dB
- FIM distortion at recommended tracking force, DIN 45.542: < 1%
- Tracking ability @ 315Hz @ recommended tracking force: 65µm
- Compliance, dynamic, lateral: 20µm/mN
- Stylus type: Elliptical
- Stylus tip radius: 0.3 x 0.7 mil
- Tracking force range: 1.5-2.0g (15-20mN)
- Tracking force, recommended: 1.75g (17.5mN)
- Color: Black

ORTOFON STYLUS FOR ORTOFON OMT-5E OMT5E CARTRIDGE

The Ortofon Stylus 5E needle stylus for the Ortofon OMT-5E OMT5E phono cartridge features a highly polished elliptical diamond for superb tracking and tracing of record grooves. It results in finer detail and harmonically complete sound quality.

If you seek further listening pleasure and improved sound quality, you can easily upgrade to a higher level of performance by replacing the Ortofon Stylus 5E stylus with an Ortofon Stylus 10, 20, 30 or 40 stylus.

Ortofon Stylus 5E Specifications
- Frequency range: 20Hz-25kHz
- Frequency response: 20Hz-20kHz +2dB
- FIM distortion at recommended tracking force, DIN 45.542: < 1%
- Tracking ability @ 315Hz @ recommended tracking force: 65µm
- Compliance, dynamic, lateral: 20µm/mN
- Stylus type: Elliptical
- Stylus tip radius: 0.3 x 0.7 mil
- Tracking force range: 1.5-2.0g (15-20mN)
- Tracking force, recommended: 1.75g (17.5mN)
- Color: Black

ORTOFON STYLUS FOR ORTOFON SMB-5 SMB5 CARTRIDGE

The Ortofon Stylus 5E needle stylus for the Ortofon SMB-5 SMB5 phono cartridge features a highly polished elliptical diamond for superb tracking and tracing of record grooves. It results in finer detail and harmonically complete sound quality.

If you seek further listening pleasure and improved sound quality, you can easily upgrade to a higher level of performance by replacing the Ortofon Stylus 5E stylus with an Ortofon Stylus 10, 20, 30 or 40 stylus.

Ortofon Stylus 5E Specifications
- Frequency range: 20Hz-25kHz
- Frequency response: 20Hz-20kHz +2dB
- FIM distortion at recommended tracking force, DIN 45.542: < 1%
- Tracking ability @ 315Hz @ recommended tracking force: 65µm
- Compliance, dynamic, lateral: 20µm/mN
- Stylus type: Elliptical
- Stylus tip radius: 0.3 x 0.7 mil
- Tracking force range: 1.5-2.0g (15-20mN)
- Tracking force, recommended: 1.75g (17.5mN)
- Color: Black

ORTOFON STYLUS FOR ORTOFON VINYL MASTER RED CARTRIDGE

Ortofon Stylus 305 stylus for Ortofon Vinyl Master Red cartridge.

Ortofon Stylus 305 Specifications
- Frequency range: 20-20kHz
- Frequency response: 20-18kHz +/-2dB
- FIM distortion @ recommended tracking force, DIN 45.542: <1%
- Tracking ability @ 315Hz @ recommended tracking force: 60µm
- Compliance, dynamic, lateral: 20µm/mN
- Stylus type: Spherical
- Stylus tip radius: 0.7 mil
- Tracking force range: 1.25-2.0g
- Tracking force, recommended: 1.5g
- Color: Grey

ORTOFON STYLUS NF-15D MKII NF15D MKII STYLUS

The genuine Ortofon Stylus NF-15D MKII NF15D MKII stylus is used with the Dual Ortofon FF-15D MKII FF15D MKII phono cartridge.

Upgrade Options
- For a stylus replacement that offers higher fidelity and musically compelling sound quality, refer to Related Product

ORTOFON SUPER OM 20 OM-20 OM20 PHONO CARTRIDGE
- The Absolute Sound Editors Choice & Highly Recommended Cartridge

The Ortofon Super OM20 phono cartridge has received accolades from many reviewers and end-users.

Review Summary
According to The Absolute Sound, the Ortofon Super OM20 has an elusive quality of relaxed, easy listenability that makes it among the most appealing of all pickups. The Ortofon Super OM30 is fractionally more transparent, lively, and dynamic... Both are superb trackers and achieve a level of sonic/musical performance quite disproportionate to their bargain-basement price.

*At the time of its review, the Ortofon Super OM20 was rated in the same performance category as the Shure V15VxMR.

Exclusive Technologies Deliver Superior Results
The world class performance of the Super OM20 cartridge is based on Ortofon's lightweight moving magnet system, originally introduced in the OM (Optimum Match) Series, with two (2) major refinements:

- By means of advanced computer simulation methods, Ortofon is able to define the natural pivot point of the system with unprecedented accuracy while achieving an optimum oscillation balance. This results in improved linearity, higher channel separation, and reduced distortion.

- Ortofon also developed a technique to "slit" the less than 1 mm diameter hollow pole pins, thus significantly reducing "eddy current" losses caused by magnetic hysteresis. This sophisticated technology extends the frequency range and improves phase linearity.

Upgradeable Performance
All Super OM models have the same body, construction, and magnetic circuitry. The only difference is the interchangeable stylus unit. Thus, when your level of musical sophistication improves, you can simply switch the existing stylus to the Ortofon Stylus 30 or for pinnacle performance the Ortofon Stylus 40. The Stylus 40 offers pinnacle performance for the most demanding listener.

Ortofon Super OM20 Phono Cartridge Specifications
- Output voltage @ 1kHz: 4mV
- Channel balance @ 1kHz: 1.5dB
- Channel separation: 22dB @ 1kHz; 15dB @ 15kHz
- Frequency range: 20Hz-27kHz
- Frequency response: 20Hz-20kHz +2/-1dB
- FIM distortion @ recommended tracking force, DIN 45.542: <1%
- Tracking ability @ 315Hz @ recommended tracking force: 80 m
- Compliance dynamic lateral: 25 m/mN
- Stylus type: Nude elliptical
- Stylus tip radius: r/R 8/18 m
- Stylus tip mass: 0.4 mg
- Tracking force: 1.25 - 1.75 g (12.5 - 17.5 mN)
- Recommended tracking force: 1.5 g (15 mN)
- Tracking angle: 20
- Internal impedance DC resistance: 1k ohms
- Internal inductance: 580 mH
- Recommended load resistance: 47k ohms
- Recommended load capacitance: 200 - 400 pF
- Color: Black
- Weight: 5 g

Stylus Replacements
- Standard stylus: Ortofon Stylus 20
- Upgrade stylus: Ortofon Stylus 30

ORTOFON SUPER OM-30 OM 30 OM30 PHONO CARTRIDGE

The Ortofon Super OM30 phono cartridge has received accolades from many reviewers and end-users. Most recently, the Ortofon Super OM30 and the Super OM20 cartridges received the very prestigious Editors Choice Award from The Absolute Sound.

Review Summary
According to The Absolute Sound, the Ortofon Super OM20 has an elusive quality of relaxed, easy listenability that makes it among the most appealing of all pickups. The Ortofon Super OM30 is fractionally more transparent, lively, and dynamic... Both are superb trackers and achieve a level of sonic/musical performance quite disproportionate to their bargain-basement price.

*At the time of its review, the Ortofon Super OM30 was rated in the same performance category as the Shure V15VxMR.

Exclusive Technologies Deliver Superior Results
The world class performance of the Super OM30 cartridge is based on Ortofon's lightweight moving magnet system, originally introduced in the OM (Optimum Match) Series, with two (2) major refinements:

-By means of advanced computer simulation methods, Ortofon is able to define the natural pivot point of the system with unprecedented accuracy while achieving an optimum oscillation balance. This results in improved linearity, higher channel separation, and reduced distortion.

-Ortofon also developed a technique to "slit" the less than 1 mm diameter hollow pole pins, thus significantly reducing "eddy current" losses caused by magnetic hysteresis. This sophisticated technology extends the frequency range and improves phase linearity.

Upgradeable Performance
All Super OM models have the same body, construction, and magnetic circuitry. The only difference is the interchangeable stylus unit. Thus, when your level of musical appreciation reaches a new constellation, you can simply switch the existing stylus to the Ortofon Stylus 40. It offers pinnacle performance for the most demanding and sophisticated listener.

Ortofon Super OM30 Phono Cartridge Specifications
- Output voltage @ 1kHz: 4mV
- Channel balance @ 1kHz: 1.5dB
- Channel separation: 25dB @ 1kHz; 15dB @ 15kHz
- Frequency range: 20Hz-29kHz
- Frequency response: 20Hz-20kHz +2/-0dB
- FIM distortion @ recommended tracking force, DIN 45.542: <1%
- Tracking ability @ 315Hz @ recommended tracking force: 90 m
- Compliance dynamic lateral: 25 m/mN
- Stylus type: Nude fine line
- Stylus tip radius: r/R 8/40 m
- Stylus tip mass: 0.3 mg
- Tracking force: 1.25 - 1.75 g (12.5 - 17.5 mN)
- Recommended tracking force: 1.5 g (15 mN)
- Tracking angle: 20
- Internal impedance DC resistance: 1k ohms
- Internal inductance: 580 mH
- Recommended load resistance: 47k ohms
- Recommended load capacitance: 200 - 400 pF
- Color: Black
- Weight: 5 g

Stylus Replacements
- Standard stylus: Ortofon Stylus 30
- Upgrade stylus: Ortofon Stylus 40

ORTOFON SUPER OM 40 OM40 CARTRIDGE

The OM 40 is the ultimate cartridge within the Super OM series - and some say the best moving magnet cartridge made by Ortofon. With its Fritz Gyger stylus, it resolves the grooves with celestial eloquence, clarity and grace. Its classic Ortofon performance and highly regarded musicality rival the high energy sound of the best 2M series.

Ortofon Super OM40 Phono Cartridge Specifications
- Output voltage @ 1kHz: 4mV
- Channel balance @ 1kHz: 1.0dB
- Channel separation: 25dB @ 1kHz; 15dB @ 15kHz
- Frequency range: 20Hz-30kHz
- Frequency response: 20Hz-20kHz +2/-0dB
- FIM distortion @ recommended tracking force, DIN 45.542: <1%
- Tracking ability @ 315Hz @ recommended tracking force: 90 m
- Compliance dynamic lateral: 25 m/mN
- Stylus type: Nude FG 70
- Stylus tip radius: r/R 7/70 m
- Stylus tip mass: 0.3 mg - Tracking force: 1.25 - 1.75 g (12.5 - 17.5 mN)
- Recommended tracking force: 1.5 g (15 mN)
- Tracking angle: 20
- Internal impedance DC resistance: 1k ohms
- Internal inductance: 580 mH
- Recommended load resistance: 47k ohms
- Recommended load capacitance: 200 - 400 pF
- Color: Black
- Weight: 5 g
- Stylus replacement: Ortofon Stylus 40
